FR1200 Ribbon Gas Burner
The FR1200 Ribbon Gas Burner is part of our Spirit range of gas fire burner trays for use in custom or bespoke fireplace designs. Hand made in the UK. The FR1200 is a very large and impressive fire with a dancing ribbon of flame. 10Kw gas ribbon burner with remote. Opening size = 1200mm x 265mm, depth 315mm. The fire can be used with any existing class 1 brick or precast chimney or with a 175mm flue liner. Read technical specification in detail before ordering.
FR1200 Ribbon Gas Burner
The FR1200 Ribbon Gas Burner is part of our Spirit range of gas burners available for bespoke and custom fire designs.
The 10Kw gas burner has a dancing ribbon of flame. The FR1200 ribbon gas burner has minimal depth and has stainless steel shelves.
The fire is supplied either with a clean ribbon of flame or there is an option to add either logs or pebbles.
BURNER: The gas burner is available for both Natural Gas and LPG
POWER RATING: Natural Gas: 10Kw [45P per hour (ON FULL)], Flow Rate: 1.0m3/Hour
DIMENSIONS: See attached technical PDF specification.
CERAMICS: Choose from either a clean ribbon of flame, logs or pebbles.
GATHER UNIT: There is an option to buy a standard gather to use with the burner and this has a 200mm spigot.
ENCLOSURE DESIGN: This is a gas burner only. The buyer takes responsibility that the final enclosure and fireplace design is in line with the UKCA approval for the appliance. Read the technical specification in detail and request a copy of the install booklet perfor placing and order.
IGNITION: The fire is operated by a RF (radio frequency) battery powered remote system with handset. The batteries have a life of 12 months or greater depending on usage. High quality batteries should be used. The handset shows the condition of the batteries in the handset and also the fire. The remote includes a thermostat to regulate the room temperature.
CHIMNEY or FLUE SYSTEM: The minimum requirement is a 175mm x 3.0m length flue liner; the fire can also be fitted into a class1 or precast chimney which meets the minimum requirements. The fire has minimum depth so will fit most existing chimneys. The fire is supplied with a gather fitted. This must be used. Opening size = 1200mm x 265mm, depth 315mm.
PIPE WORK: The fire has a power rating of 10Kw and requires an 8mm gas inlet. The flow rate on full is 1.0m3 per hour, the pipework to the fire must be capable of supplying a steady inlet pressure and should be routed using at least 28mm pipes reducing to 8mm at the fire. The pipework should be routed to ensure no pressure drop when other gas appliances in the home are being used.
SAFETY: Tested to the latest UKCA safety standard. Fitted with ODS (Oxygen Depletion System) safety system which monitors oxygen levels in the room and shuts off the fire should the chimney be blocked. o It is advised that when operating the appliance in a room where children or elderly people will be present that a fireguard should be used. These are available from our web store.
VENTILATION : The fire requires an air vent which can supply a minimum of 100cm2 air. We can supply a high quality air vent with the fire. Our air vents have baffles and a draft cowl to ensure that they provide air only. Ask for details.
